    R88M-G05030H OMRON R88M Series Small Servo Phase Motor Controller

    Ask Lasest Price
    Brand Name : OMRON
    Model Number : R88M-G4K510T-S2-Z
    Certification : CE
    Price : negotiable
    Payment Terms : T/T, , L/C
    Supply Ability : 88
    Delivery Time : 5-8DAYS
    • Product Details
    • Company Profile

    R88M-G05030H OMRON R88M Series Small Servo Phase Motor Controller

    Brand:OMRONModel:R88M-G4K510T-S2-Z
    Origion:Japan
    High Light:

    ewing machine servo motor

    ,

    ac servo motor


    OMRON AC Servo Motor R88M-G4K510T-S2-Z Cylindrical and flat servo motors up to 3000 rpm 200V 4KW


    Key features and benefits:
    • Pocket-size servo with smallest
    footprint 15x4 cm
    • Auto-tuning for easy and quick start-up
    • Built-in MECHATROLINK-II motion bus reduces
    cabling and allows remote servo configuration
    and diagnosis
    • High starting torque: 300% for 3 secs.
    • Positioning, speed or torque control
    • Separate power and control power supply
    • Fast and accurate positioning
    • Servomotor range from 50 W to 1.5 kW
    • Incremental and absolute encoder available
    • Cylindrical and flat servo motors
    up to 3,000 rpm
    • Compatible with SmartStep 2 servomotors
    • Vibration suppression



    Fast and simple auto-tuning
    The graphs show a move profile with a G-series servo in an
    application with an inertia ratio of 16:1. Tuning is possible via the
    easy to use CX-Drive, and takes just 1 minute to complete.
    The result is superb control, ensuring the servo and hence machine
    operates at its optimal point, with next to zero knowledge required
    from the user.
    Once running, the on-board real time auto-tuning function takes care
    of the servo operation relative to the load inertia, again ensuring the
    quality of the finished produced part.
    In addition, numerous suppression and notch filters are available to
    suppress machine vibration independent of machine direction.



    NCF – key features and benefits
    • 16 axes, point-to-point positioning over ML II
    • System scalability with models for 2, 4 and 16 axes
    • Easy, quick and reliable setup
    • Optimized for positioning applications
    • Simplified wiring to drives
    • Integration with Omron Smart Platform



    Compact in size big in features. Save space, save wiring, save time
    • Built-in MECHATROLINK-II motion bus
    • Position, speed and torque control
    • High-response frequency of 1 kHZ
    • Real time auto-tuning
    • Vibration suppression
    • Separate power and control power supply
    • Available motors with absolute and incremental with 17-bit encoder for greater accuracy
    • Cylindrical and flat servo motors up to 3000 rpm
    • Servomotors supported by SmartStep2, G-Series and G5-Series servo drives
    • Peak torque 300% of continuous torque during 3 seconds or more depending on model
    • IP65 and shaft oil seal available Ratings
    • 230 VAC single-phase 100 W to 1.5 kW (8.62 Nm)



    Easy connection: single cable only!
    With their built-in MECHATROLINK-II motion bus, just
    a single cable is needed to connect servos together.
    So you not only save on wiring and installation time,
    you also significantly reduce the chance of
    connection errors. Reliability is increased since the
    single-cable connection is much more rugged than a
    multiple-wiring solution.


    2,000-r/min Servomotors


    SpecificationsModel
    Without oil seal
    Straight shaftWith key and tap
    Without brake200 VAC1 kWR88M-1M1K020TR88M-1M1K020T-S2
    1.5 kWR88M-1M1K520TR88M-1M1K520T-S2
    2 kWR88M-1M2K020TR88M-1M2K020T-S2
    3 kWR88M-1M3K020TR88M-1M3K020T-S2
    400 VAC400 WR88M-1M40020CR88M-1M40020C-S2
    600 WR88M-1M60020CR88M-1M60020C-S2
    1 kWR88M-1M1K020CR88M-1M1K020C-S2
    1.5 kWR88M-1M1K520CR88M-1M1K520C-S2
    2 kWR88M-1M2K020CR88M-1M2K020C-S2
    3 kWR88M-1M3K020CR88M-1M3K020C-S2
    With brake200 VAC1 kWR88M-1M1K020T-BR88M-1M1K020T-BS2
    1.5 kWR88M-1M1K520T-BR88M-1M1K520T-BS2
    2 kWR88M-1M2K020T-BR88M-1M2K020T-BS2
    3 kWR88M-1M3K020T-BR88M-1M3K020T-BS2
    400 VAC400 WR88M-1M40020C-BR88M-1M40020C-BS2
    600 WR88M-1M60020C-BR88M-1M60020C-BS2
    1 kWR88M-1M1K020C-BR88M-1M1K020C-BS2
    1.5 kWR88M-1M1K520C-BR88M-1M1K520C-BS2
    2 kWR88M-1M2K020C-BR88M-1M2K020C-BS2
    3 kWR88M-1M3K020C-BR88M-1M3K020C-BS2
